United States Bullet Proofing Products: Windows
USAW 300 - Bullet/Blast Resistant Interior Fixed Aluminum Window System

Single Lite
Multi-Lite
Transaction

The 300 Series window is a fixed aluminum blast and ballistic window designed for interior applications, such as a transaction window.


Summary
  • Ballistics – UL 752 Levels 1-8, NIJ I, II-A, II, III-A, III
  • Blast – Exceeds GSA DOD (UFC)
  • Forced Entry – ASTM F1233 and F588
  • Frame Size – 1 1/4" W x 3 3/4" D with custom sizes available
  • Glazing Thickness – 1/4" to 2 1/4"
  • Applications – Transaction windows in secure office within a building.

Details
  • The USAW300 Window Series is shipped non-glazed and factory assembled. The window is a non-thermal type for interior applications. The unit is available as a single lite, multi lite or transaction window.
  • The USAW300 Window Series construction consists of heavy-duty aluminum extrusion and 1/8” minimum wall thickness. The extrusions allow for the insertion of armor consistent with specified threat level.
  • Glass components are easily replaceable.
  • Blast protection available.
  • Standard finish: Clear or bronze anodized (custom Kynar paint, brass cladding, stainless steel cladding available)
    It is recommended that the window be used in conjunction with protected
    wall and door areas.

    Each end user should determine the blast, ballistic and forced entry threat level to ensure the correct product selection to meet and exceed security needs.
